Max Deck System

Max Deck System

Max Deck System will be very effective for obtaining a 3-4 day slab cycle for a typical project. The shuttering speed clocked till date is approx. 350 sq. ft. per man hour and de-shuttering at 650 sq. ft. per man hour. The number of components is the lowest as compared to any system which is essential when working at great heights. The panels are automatically wind locked during assembly which is very important at heights.

Some of the key features are:-

  • » Modular design. The system can be easily expanded and reduced for changing slab heights and areas.
  • » System is safely erected and stripped from the floor below.
  • » System’s Panels can be removed at 2000 psi without disturbing props or concrete.
  • » System’s Panels are wind locked automatically during assembly and this is a very important factor when using slab decking in areas prone to high winds.
  • » System can be erected in any or all of 4 directions simultaneously.
  • » System requires no "x" bracing.
  • » The 2 main components, Panel & Prop, automatically interlock against strong wind loads.
  • » System's heaviest component, an 8' X 4' panel, can be carried by any 2 men.
  • » System’s Telescopic, Side, and End Filler Beams make shoring around columns and other interruptions easy, efficient, and cost-effective.
  • » System’s components are not welded.
  • » System’s Components are sturdy and durable for ease of handling and longevity.
